iiyama TE7513A-B2AG Signage Display Interactive flat panel 190.5 cm (75") Wi-Fi 500 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 24/7

Name: iiyama TE7513A-B2AG Signage Display Interactive flat panel 190.5 cm (75") Wi-Fi 500 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 24/7
Brand: IIYAMA CONSIGNMENT
SKU: 456281
Price: 2308.90 EUR
Availability: OutOfStock

2 308,90 €

Be PVM: 1 908,18 €

Pirkite išsimokėtinai su ESTO

Likutis tiekėjo sandėlyje: Neturime
Prekės ženklas: IIYAMA CONSIGNMENT
Modelis: TE7513A-B2AG
Pakuotės svoris: 62,5 kg
Išmatavimai: 186 × 114 × 19 cm
Barkodas: 4948570125746
Prekės kodas: 456281

Tikslinama individualiai

GA–G Gaminio informacijos lapas

2 308,90 € Be PVM: 1 908,18 €

Kiekis

2 m. garantija pagal įstatymąTeisinė garantija, kaip visoms naujoms prekėms ES
14 dienų grąžinimasNepatiko? Grąžinkite be klausimų
Patogus atsiskaitymasKortele, Apple Pay, Google Pay, išsimokėtinai
Pristatymas visoje LietuvojeDPD į namus, paštomatai arba atsiėmimas Vilniuje

Įsiminti PDF kortelė

Pagrindinės savybės

Indoor Interactive flat panel Black
190.5 cm (75") 3840 x 2160 pixels 500 cd/m²
Touchscreen 8 ms
Ethernet LAN Wi-Fi
Built-in speaker(s) 60 W

Žymės: iiyama consignment nestandartiniai monitoriai , iiyama consignment nestandartiniai monitoria

The TE7513A-B2AG is a cutting-edge 4K UHD Google EDLA Certified interactive display that redefines performance and precision. Featuring a Zero-Gap Air Bonding LCD screen to eliminate parallax and with PureTouch-IR+ with Palm Rejection, it ensures smooth, accurate interaction. Powered by iiWare 21E with Android 14-EDLA, WiFi-6E with Bluetooth 5.0 connectivity, iiControl (DMS), iiShare and integrated EShare app (wireless screen sharing), it integrates seamlessly into your ecosystem. Enjoy added features like a PIR motion sensor for energy efficiency; perfect for workplaces and educational spaces, it fosters collaboration, communication, and progress.

Display
Display diagonal	190.5 cm (75")
Display resolution	3840 x 2160 pixels
Display brightness	500 cd/m²
HD type	4K Ultra HD
Touchscreen	Yes
Panel type	IPS
Touchscreen technology	PureTouch-IR
Number of simultaneous touchpoints	40
Native aspect ratio	16:9
Response time	8 ms
Contrast ratio (typical)	1200:1
Viewing angle, horizontal	178°
Viewing angle, vertical	178°
Display number of colours	1.07 billion colours
Pixel pitch	0.4296 x 0.4296 mm
Active display area (W x H)	1650 x 928 mm
Display diagonal (metric)	189.3 cm
Horizontal scan range	30 - 135 kHz
Haze rate	25%
Surface hardness	7H
Touch response time	5 ms
Glass thickness	3.2 mm
Ports & interfaces
HDMI ports quantity	3
DisplayPorts quantity	1
USB port	Yes
HDMI input ports quantity	1
HDMI output ports quantity	1
DisplayPort version	1.2
USB ports quantity	5
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-A, USB Type-C, USB Type-B
USB 2.0 Type-B ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	100 W
USB Type-C DisplayPort Alternate Mode	Yes
Ethernet LAN (RJ-45) ports	2
RS-232C	Yes
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
OPS module slot	Yes
Audio Return Channel (ARC)	Yes
Audio
Built-in speaker(s)	Yes
Number of built-in speakers	2
RMS rated power	60 W
Design
Product design	Interactive flat panel
Product colour	Black
Placement supported	Indoor
VESA mounting	Yes
Orientation	Horizontal
Panel mounting interface	800 x 400 mm
Bezel width (bottom)	4.1 cm
Bezel width (side)	1.65 cm
Bezel width (top)	1.65 cm
Bezel colour	Black
Anti-glare screen	Yes
Positioning accuracy	1 mm
Performance
Purpose	Education
On Screen Display (OSD)	Yes
Number of OSD languages	13
On Screen Display (OSD) languages	Czech, Danish, German, English, Spanish, Estonian, Finnish, French, Hungarian, Italian, Lithuanian, LAT, Norwegian, Dutch, Polish, Russian, Swedish, Ukrainian
Operating hours (hours/days)	24/7
HDCP	Yes
HDCP version	2.2
Mean time between failures (MTBF)	50000 h
Power
Power consumption (typical)	217 W
Power consumption (standby)	0.5 W
Power consumption (off)	0.3 W
Energy efficiency class (SDR)	G
Energy efficiency class (HDR)	Not available
Energy consumption (SDR) per 1000 hours	188 kWh
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Computer system
Computer system	Yes
Built-in processor	Yes
Processor architecture	ARM Cortex-A53+Cortex-A72
Internal memory	8 GB
On-board graphics card model	ARM Mali-G52
Internal storage capacity	128 GB
Operating system installed	Android
Operating system version	14
Weight & dimensions
Display width	1710 mm
Display depth	87 mm
Display height	1016 mm
Display weight	51.8 kg
Width	1710 mm
Depth	87 mm
Height	1016 mm
Weight	51.8 kg
Packaging data
Package width	1860 mm
Package depth	185 mm
Package height	1125 mm
Package weight	63 kg
Packaging content
Remote control included	Yes
Stylus pen	Yes
Number of stylus pens	4
Cables included	AC, USB, HDMI
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Logistics data
Products per pallet	4 pc(s)
Network
Ethernet LAN	Yes
Wi-Fi	Yes
Ethernet LAN data rates	1000 Mbit/s
Wi-Fi standards	Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b, 802.11g, 802.11a
Technical details
OPS slot	1
Sustainability certificates	ErP
Warranty period	5 year(s)
Compliance certificates	REACH, RoHS, WEEE
Audio in (mini jack)	Yes
Playback media	Y
User controls	general settings (input, volume, backlight), audio (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode colour temp), settings (wireless & networks, share, device, personal, system)
Other features
Quick start guide	Yes
Bluetooth	Yes
Bluetooth version	5
Brightness	500 cd/m²
Compatible operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Power supply type	Internal
